Introduction
The 8th-generation 132KW XGJ560 ring die biomass pellet making machine is a newly optimized commercial pelletizing equipment tailored for global medium and large-scale biomass enterprises pursuing low failure rate and easy maintenance. Different from conventional upgraded models that only boost power, this 8th-gen version focuses on overall matching optimization of the whole machine, solving the common mismatch between feeding speed and host extrusion efficiency of high-power pellet machines. With a scientific rated output of 1.5–2T/H, it perfectly balances high production volume and stable molding effect.
The whole machine adopts a standardized modular design, with all core running parts and electrical accessories uniformly equipped with first-line domestic brands, realizing unified quality standards and convenient overseas replacement. The upgraded 3KW independent feeding system and new-generation gear reduction system form a high-efficiency production combination. Verified by actual Indian project operation, this equipment features simple operation, strong compatibility and low maintenance difficulty, being a cost-effective mainstream model for global medium-sized pellet factories to upgrade and replace old equipment.
Parameters
8TH(132KW) XGJ560 Pellet Machine | - Output: 1.5-2T/H - Power (kw): 132+3+0.75+0.75+0.25kw -Number of rollers: 2 pcs -Pellet diameter option :6, 8,10,12mm -Weight of machine (kgs):5200kg - Dimension(mm):2100*1700*1600 - New generation Gear reducer system Whole set include: *Pellet push system 3kw *Gear oil lubricate pump 0.75kw *Cyclone dust collector 0.75kw *Automatic roller lubrication pump 0.25kw *Electric control Box (Soft Start) |
Application
This 8th-generation high-standard pellet machine is mainly applied in localized biomass resource utilization and commercial fuel promotion projects. It targets regional scattered biomass resources, making full use of local abundant forest pruning waste, shrub residues and wood processing leftovers that are difficult to store and dispose of. It realizes on-site recycling and value-added transformation of local waste resources.
The produced 6–12mm multi-specification pellets meet local industrial combustion standards and cross-border export inspection norms. The finished clean fuel can be stably supplied to local industrial parks, commercial heating projects and biomass power stations for fossil energy replacement. It also supports cross-border green energy export trade, helping local investors build characteristic circular economy projects and quickly occupy the regional clean biomass fuel market.
Advantages
This 8th-generation pellet machine has a unique overall matching advantage that distinguishes it from ordinary models. The upgraded 3KW high-power feeding system and 132KW main engine achieve precise speed matching, completely solving the industry common problems of material overflow, empty extrusion and uneven molding caused by mismatched feeding and host power. The whole machine adopts brand-matched core accessories including TAIBANG reducer, QINGDAO motor, CHINT electrics and HRB bearings, with coordinated performance of all parts and no drag operation.
The equipment features extremely low daily failure rate and stable long-term operation. The supporting VFD soft-start system can adapt to unstable voltage and frequency fluctuations in overseas factories, effectively protecting the whole machine circuit and power components. Compared with ordinary assembled pellet machines, it has stronger operational stability, lower shutdown maintenance frequency, and effectively improves the effective production time and comprehensive output benefit of pellet factories.
FAQ
Q1: How does the supporting cyclone dust collector optimize workshop production environment?
A1: The 0.75kw high-efficiency cyclone dust removal device captures fine wood and biomass dust generated during processing. It reduces dust accumulation inside the machine and in the workshop, lowers equipment failure caused by dust blockage, and meets modern factory environmental protection operating standards.
Q2: Is the XGJ560 132KW unit friendly for new factory operation?
A2: Absolutely. The whole machine is equipped with a professional soft-start electric control box, which simplifies startup operation and avoids current impact. The integrated auxiliary system realizes semi-automatic operation, reducing manual operation difficulty and allowing novice workers to master production quickly.
Q3: What raw materials is this 132KW pellet machine most suitable for processing?
A3: It shows excellent adaptability for common wood chips, sawdust, branch fragments and general agricultural biomass residues. With balanced compression ratio and moderate output of 1.5–2T/H, it is the most suitable model for medium-sized biomass factories with mixed raw material processing needs.
Q4: How flexible is the pellet size adjustment of this equipment?
A4: The machine supports four mainstream pellet specifications: 6mm, 8mm, 10mm and 12mm. Users can replace ring dies according to market demand to switch pellet sizes freely, covering fuel needs for industrial boilers, civil heating and biomass energy sales.
